| ブランド名: | AE |
| モデル番号: | AE100 |
| Moq: | 10平方メートル |
| 価格: | USD 80-108 Per Square Meter |
| 支払条件: | L/C、D/A、D/P、T/T、ウェスタンユニオン、マネーグラム |
| 供給能力: | 月額1000平方メートル |
Our high-quality acoustic partition walls, also known as sliding folding partitions or room dividers, feature a sturdy aluminum frame construction with customizable sizes, performance levels, and decorative finishes. Manufactured to international standards, these partitions combine functionality with aesthetic appeal.
Available in three different wall thicknesses, our partitions offer exceptional durability and can accommodate taller structures. Choose from a wide selection of acoustic and decorative surface options to meet your specific requirements.
Engineered to minimize sound transmission, our partitions significantly reduce acoustic reflections and improve soundproofing. Ideal for creating private spaces within larger areas while maintaining superior sound insulation.
Our movable soundproof partition system features an overhead track mechanism for smooth operation. Perfect for hotels, banquet halls, and large venues, these partitions offer both flexibility and exceptional performance.
| Series | Element thickness (mm) | Element width* (min/max) | Clear height* (min/max) | Construction | Panel fixing | Element interconnection |
|---|---|---|---|---|---|---|
| AE65 | 68 | 600/1,250 | 2,000/4,500 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| AE85 | 89 | 600/1,250 | 2,000/5,500 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| AE100 | 105 | 600/1,250 | 2,000/18,000 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
Technology: Weighted sound reduction value (Rw): 52/56 dB (GB/T19889.3-2005 standard)
Note: Larger widths available upon request. Final dimensions subject to design consultation.
