| ブランド名: | AE |
| モデル番号: | AE65 |
| Moq: | 10平方メートル |
| 価格: | USD 70-98Per Square Meter |
| 支払条件: | L/C、D/A、D/P、T/T、ウェスタンユニオン、マネーグラム |
| 供給能力: | 月額1000平方メートル |
Office Acoustic Operable Partition Wall System with wooden finish
Our cost-effective soundproof movable partition wall systems feature built-in passageway doors, providing both privacy and accessibility. These partitions create quiet, adaptable spaces while maintaining budget efficiency.
| Series | Element Thickness (mm) | Element Width (min/max mm) | Clear Height (min/max mm) | Construction | Panel Fixing | Element Interconnection |
|---|---|---|---|---|---|---|
| AE65 | 68 | 600/1,250 | 2,000/4,500 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| AE85 | 89 | 600/1,250 | 2,000/5,500 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
| AE100 | 105 | 600/1,250 | 2,000/18,000 | Aluminium-steel | Freely oscillating | Aluminium profile with magnetic strip and sealing lips |
Technology: Weighted sound reduction value (Rw): 52/56 dB (determined per GB/T19889.3-2005)
Element Connections: Positive and frictional locking with convex-concave profile form, magnetic strip attraction force of 40 N/m
* Larger widths available upon request. Final dimensions subject to Design Department confirmation.
